Asus Rog Strix B760-G Gaming WIFI D4 (90MB1DE0-M0EAY0)
SKU: 12563
| Brand | Asus |
| Series | ROG Strix |
| Model/PN | 90MB1DE0-M0EAY0 |
699.00 ₾
მარაგშია
თვეში 29 ₾ -დან
✓ მიწოდება მთელი ქვეყნის მასშტაბით
თვეში 29 ₾ -დან
General Information
- Brand: Asus
- Series: ROG Strix
- Model/PN: 90MB1DE0-M0EAY0
Dimensions
- Dimensions (Height x Width x Depth): 24.4 x 24.4 cm cm
Motherboard Features
- Compatibility Processors: Intel Socket LGA1700 for 13th Gen Intel & 12th Gen Intel Core, Pentium Gold and Celeron
- Form Factor: Micro ATX
- Socket: LGA1700
- Chipset: B760
- Memory Slots Type: DIMM
- Memory MHz: 5333(OC)/ 5066(OC)/5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133
- Memory Type: DDR4
- Number Of Memory Slots: 4
- Max RAM Memory: 128 GB
- BIOS: 256 Mb Flash ROM, UEFI AMI BIOS
Expansion Slots
- PCIe 5.0 x16: 1
- PCIe 4.0 x16: 1 , 2 x PCIe 4.0 x1 slots
Storage
- M2 Slots: 2
- Raid Support: 0, 1, 5, 10
- SATA 6Gb/s Connectors: 4
- Intel Rapid Storage Technology support: Yes
Motherboard Connectivity
- Bluetooth: 5.3
- Wi-Fi Antenna: Yes
- Supported Wi-Fi Standards: Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
LAN Controller
- LAN Controller: Intel
- LAN Speed: 2.5Gbs
Motherboard Audio
- System: Savitech
- Audio Controller: SV3H712 AMP
- Number Of Audio Channels: 7.1
- 32-Bit/192kHz Playback: Yes
- SupremeFX Shielding Technology: Yes
Back I/O Ports
- HDMI: 1
- USB 3.2: 2
- USB 2.0: 4
- DisplayPort: 1
- USB Type-C: 2
- LAN (RJ45): 1x 2.5Gb
- Audio Jacks: 5
- USB BIOS Flashback Button: 1
Internal I/O Ports
- M.2 Socket 3 for M Key: 2
- SATA 6Gb/s Connectors: 4
- 24-pin Power Connector: 1
- 4-pin Power Connector: 1
- 8-pin Power Connector: 1
- CPU Fan Connector: 1
- USB 3.2: 1
- CPU OPT Fan connector: 1
- USB 2.0: 2
- Chassis Fan Connector: 2
- USB Type-C: 1
- S/PDIF Out Header: 1
- Front Audio Connector: 1
- System Panel: 1
- Thermal Sensor Connector: 1
- Thunderbolt header: 1
- Clear CMOS Jumper: 1
- 3-Pin ARGB: 1
